BREAKSAFE Remote Battery Monitor RM6000 Caravan RV Camper Breakaway Break Safe

R.V. Electronics BREAKSAFE RM6000 Remote Battery Monitor

Product Description:

The BREAKSAFE RM6000 Remote Battery Monitor is fitted inside the tow vehicle and operates each time the brake pedal is pressed. The additional circuitry in the BREAKSAFE 5000 and 6000 disconnects the Breaksafe battery from the charge circuit and then connects the battery to the Remote Monitor. A small electronic load inside the Remote Monitor then pulls the battery terminal voltage down. The microprocessor inside the Remote Monitor measures what the voltage drops to over a preset time to determine the charge state of the Breaksafe battery. Should the Breaksafe battery be fully charged, a green light will illuminate on the front panel of the RM6000 Remote Monitor. If the battery is below the safe level, a red light will flash and a buzzer will sound for about 10 seconds.

The RM6000 Remote Battery Monitor can only be used in conjunction with a Breaksafe 5000 or 6000 breakaway kit. It will not work correctly when connected to any other breakaway system.

SIZE - W64mm x D50mm x H22mm

A REMOTE BATTERY MONITOR IS REQUIRED BY THE NSW RTA TO BE FITTED TO THE TOW VEHICLE FOR REGISTRATION IN NSW.

WARNING:
To comply with NSW regulations, only connect a Breaksafe 5000 or 6000 with a Breaksafe or Redarc Remote Battery Monitor.
Connecting any other brand voltage monitor will void all warranty on your Breaksafe and breakaway battery.
